PeakTech® 1235

32 CH logic analyzer with USB and RS-232 C

This digital logic analyzer provides basic functions, easy operation and a new type of data acquisition to monitor and measure digital signals into digital information processes.

This unit realizes the design and troubleshooting of digital system, as well as to analyze transmission delays and represent the result of the information processing of the digital circuit and bus technology.

15 cm (5,7”) color LCD display
32 input channels
256 k points storage depth
Simultaneous display of 8 timing wave forms
FPGA and SOPC logic technology
Start, trigger and delay for effective data acquisition
Hardware and software debugging tool for MCUs
Two external clock channels
USB and RS232 interface
Safety: EN-61010-1
Accessories: USB cable, power cable, logic probes, software CD for Windows 2000/XP/Vista/7 and operation manual

Download Manual

PeakTech_1235

Display	15 cm, 5,7” LCD (320 x 230 Pixel)
Timing wave forms	8 channel
Data lists	18
Zoom	1 : 10; 1 ns/DIV to 45/DIV
Input channels	32 (2 x 16)
Input range	500 mVpp to 20 Vpp
Input impedance	> 100 kΩ; < 8 pF
Input voltage	40 V DC or ACpp
Treshold voltage	6 independently adjustable threshold voltages
Adjusting range	-6 to +6 V; 0,1 V resolution
Sample rate	internal clock; 1 Hz ~ 100 MHz (10 ns - 1 S) / external clock; 1 Hz ~ 3,5 MHz
Storage depth	256 k points for each channel
Trigger conditions	32 Bits Trigger select
Trigger limit	›, =, ‹
Event counter	1 ~ 999
Store delay	1 ~ 256 k
Operation voltage	100 ~ 240 V ACrms / 60 Hz
Dimensions (WxHxD)	340 x 160 x 283 mm
Weight	3 kg
EAN-13	4250569400247
