PeakTech® 2165 USB
THB 6,000.00
Digital LCR-Meter, 120 Hz-1kHz with USB
Digital LCR meter with 4 ½ digit dual multifunction LCD-display. The dual display feature permits simultaneous measurements. Components can be measured in the series or parallel mode and the LCR-meter is auto or manual ranging.
- USB interface
- Basic accuracy:
- 0,5 % resistance
- 0,7 % capacitance
- 1,2 % inductance
- Excellent resolution:
- resistance up to 0,001 Ω
- inductance/capacitance up to 0,1µH/0,1 pF
- Auto power off (switching off permanent measurements)
- Defective fuse warning
- Relative measurement
- Switchable testfrequencies: 120 Hz/1 kHz
- Min-Max/Hi-Lo/tolerance-display
- Accessories: USB interfacecable, software for Windows 95/98/NT/2000/XP/VISTA/7/8/10, testleads, holster, battery and manual
| Measurement modes | Ls, Lp, Cs, Cp, D, Q, R |
| Capacitance measurement ranges | 20/200 nF/2/20/200µF/2/10 mF ± 0,7 % + 5 St. / dgt.; 0,1 pF |
| Inductance ranges | 20/200 mH/2/20/200H/2/10 kH ± 1,2 % + 5 St. / dgt.; 0,1 µH |
| Ohm ranges | 20/200Ω/2/20/200 kΩ/2/10 MΩ ± 0,5 %; 1 mΩ |
| Operation voltage | 9 V battery or external Power adapter 12 V- 50 mA DC |
| Dimensions (W x H x D) | 91 x 192 x 53 mm (incl. Holster) |
| Weight | 365 g |
| EAN-13 | 4250569400438 |
